NVR HD 4 Kanalni VIDEO SNIMAČ HIKVision DS-7604NIK

Name: NVR HD 4 Kanalni VIDEO SNIMAČ HIKVision DS-7604NIK
SKU: 07446
Price: 197.01 EUR
Availability: OutOfStock

197,01 EUR

NVR HD 4 Kanalni VIDEO SNIMAČ HIKVision DS-7604NIK je moderne tehnologije, sa IP video ulazom za 4 kamere visoke rezolucije do 5 megapiksela. Ovaj samostalni snimač podržava HDD kapaciteta do 4000 GB po disku, sa 2 SATA sučelja. Također, dolazi sa 4-portnim PoE switchem koji se potpuno integrira s Hikvision IP kamerama. Sa podrškom za IE, Google Chrome, Opera i Safari web pretraživače, NVR omogućava stabilno snimanje i reprodukciju slike visokog kvaliteta. Svi ovi vrhunski karakteristike čine ga idealnim za praćenje dinamičnih okolina kao što su ulice, parkirališta i autobuske stanice. Dolazi s korisničkim programima iVMS, NVR Server i StreamServer. Uređaj radi na Windows i MAC OS X operativnim sustavima.

Dostupnost: Trenutno nije dostupno

SKU

07446

Obavijesti me kada se cijena spusti

Obavijesti me čim proizvod bude omogućen za košaricu

Opis

• IP video ulaz: 4- ch
Do 5 megapiksela rezolucija (2560x1920)
BANDWITH SNIMANJA 20Mbps
• Dual streams
• 2 SATA sučelje do 4000 GB za svaki pojedini HDD
Dvosmjerni audio ulaz: 1-ch RCA (2.0Vp-p, 1kΩ)
Rezolucija snimanja i playbacka: 5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
HDMI izlaz: 1ch (1920x1080P/60Hz, 1920x1080P/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz) VGA izlaz: 1 ch (1920x1080P/60Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
Audio izlaz: 1-ch RCA linearni 1kΩ
Sinkronizirani playback: 4-ch 720P / 2-ch 1080P/ 1-ch 5MP

Sučelje za komunikaciju: 1 RJ45 10/100/1000 Mbps

4 neovisna 10/100Mbps PoE Ethernet sučelja

RS-485 Port: 1 ; USB sučelje: 2
Napajanje: 100-240VAC, 47-63Hz, 3A Potrošnja struje: ≤15W (bez HDD ili DVD-R/W) Radna temperatura: -10°C ~ 55°C
Vlažnost: 10% ~ 90%
Dimenzije: 445mm(Š)x290mm(D)x45mm(V) Masa: ≤2Kg (bez HDD ili DVD-R/W)

Podržava aplikacije mobilnih telefona Android, Windows I iPhone

U kompletu sa snimačem dolaze korisnički programi iVMS,NVR Server I StreamServer
Uređaj radi na Windows I MAC OS X operativnim sustavima

Hikvision DS-7604NI-SE/P is a modern IP network video recorder capable of monitoring, recording and playing back images from 4 IP cameras of megapixel resolutions at frame rates up to 25 fps from each camera. This standalone NVR with VGA and HDMI outputs can be directly connected to a monitor, without a need for an additional computer. Thanks to embedded Linux OS, the NVR ensures stable operation and resistance to computer viruses.

The local recording and network transmission uses H.264 compression that provides good image quality with relatively small bandwidth and disk space consumption. There is place for one SATA HDD with total capacity up to 4 TB. In addition, the NVR supports NAS (NFS) and SAN (iSCSI)disk arrays. The option of automatic overwriting of existing material prevents loss of the current data. Built-in USB ports can be used for control of the NVR via external devices and for connecting a USB storage device, usually to copy some data.

The NVR has built-in 4-port PoE switch, fully integrating with Hikvision IP cameras. After connecting the cameras, the NVR automatically configures the network parameters and ensures instant connectivity with them.

Thanks to the 25 fps frame rate in each channel, the NVR is ideal for monitoring dynamic environments such as streets, expressways/highways, parking lots, bus stations etc. For example, a car traveling at a speed of 60 km/h covers 16 meters a second, so a DVR recording video at 10 fps would have "linear resolution" of 1.6 meter, not acceptable in many applications (loss of a huge amount of information between consecutive frames). Hikvision DS-7604NI-SE operating at 25 fps provides video footage that is 2.5 times more accurate in this sense.

A new menu of the DVR has been designed in a manner that helps everyone, even novice users, navigate and make changes to the settings. Both the layout of commonly used functions and graphic design meet the highest current standards. Support for Google Chrome, Opera and Safari web browsers eliminates the need for installing/using ActiveX controls.

Browsing the archives locally, the user can simultaneously play them back from all 4 channels. To quickly localize the interesting moment/period, the video records are presented on timelines (24 hours). The playback can be started just by clicking on a point on a timeline.

IP CCTV systems based on Hikvision IP cameras and NVRs can be configured for continuous recording with special parameters in the case of specific events. Each channel can be configured individually in this aspect. It is possible to increase the frame and bit rates, independently of the continuous recording settings. After the occurrence of an event (motion detection, camera tampering etc), the NVR automatically switches to the event-recording mode (usually with higher parameters). During the rest of the time the recording is carried out in the continuous mode. The increased parameters just before and after the event allow to play back every second of the period with high detail and smoothness, while the recordings between events may have a much lower performance, taking significantly less space on the storage media.

HIKVISION NVRs in IP networks can be controlled via IVMS 4200 software. The software allows for configuration and management of NVRs/DVRs and IP cameras. The iVMS 4200 utility can remotely manage up to 256 NVRs/DVRs. The user accounts can have different access/management rights, from the highest level of "administrator" to individually limited "guest" levels.

Key features:

Max total bandwidth (from all cameras): 20 Mbps
Stable operation
Support for IE, Google Chrome, Opera, Safari
Simultaneously operating HDMI, VGA outputs
HDMI/VGA up to 1920x1080
Searching by motion detection and alarm events
Digital zoom
Synchronized playback of all channels simultaneously
Possibility of continuous recording with special parameters in the case of specific events (only for Hikvision cameras)
Support for IPv6
Monitoring of the status of LAN, cameras, HDDs

Compression:

H.264
Watermark
Ability to set recording parameters for each channel, including image resolution and quality, bit rate
Audio-video synchronization

Local monitoring

Screen division or sequential image displaying
Up to 4 privacy zones for each camera
Presets and patrol paths and for PTZ cameras
PTZ control via mouse by selecting some area of the image
Possibility of setting a timetable for patrol paths and starting points for PTZ cameras
Detection of video loss, motion detection in predefined areas of images
Quick playback option

Disk management

Place for one SATA HDD up to 4 TB
Support for up to 8 NAS drives (8 x NAS or 7x NAS +1x IP SAN)
Disk group management
S.M.A.R.T. hard disk monitoring
Option of overwriting existing data

Recording and playback

Multiple recording modes, including manual, scheduled or triggered by motion detection
8 periods of scheduled recording, individually configurable for each camera
Pre and post alarm options
Searching options include selection of date and time, channel, kind of recording (event)
Ability to set different recording parameters for alarm events
Timelines
Local playback of all channels simultaneously
Markings for quick searching of selected recordings
Digital zoom during live monitoring and playback
Defining image parameters for specific events
Reverse playback

Alarms

Exceptions include: disk overflow, disk failure, network failure, video loss, video incompatibility, IP conflict
Alarm response actions include: displaying full screen image from the active channel, beep, email notification
Possibility of scheduling alarm activation periods

Network operation

Built-in 10/100Mbps Fast Ethernet card
Support for IE, Google Chrome, Opera, Safari
Support for TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP protocols
Possibility of remote control, downloading of recordings via the network, remote search/playback/archiving
Remote configuration of parameters
Remote import/export of settings
Remote monitoring of the device status, alarms, log
Possibility of remote disk management, remote firmware update, remote operation control
Remote recording control (switching on/off)
Screenshot recording option

Other features:

Control via USB mouse or remote, front panel buttons, dedicated keypad
Ability to create user accounts with different access/management rights
System log recording all events; easy way to find events according to main categories: alarms, exceptions, operations etc.
Starting and stopping alarms manually or automatically
Ability to save and import/export DVR settings

Specifications:

Name/model	DS-7604NI-SE/P
Code	K2205
Manufacturer	Hikvision
Operating system	Embedded Linux
Number of channels	4
Support for megapixel cameras	YES
Max total bandwidth	20 Mbps
HDD	1x SATA II (max 4 TB)
Pentaplex	Simultaneous live monitoring, recording, playback, backup and remote access
System monitoring	External alarm, motion detection, tampering, recording failure, disk failure, disk overflow, IP network failure, IP address conflict, unauthorized login attempt
Alarm actions	Recording start, sound notification, email notification, monitoring center alert, PTZ preset tour
Live monitoring	4 channels
Playback	2 channels
Supported camera brands	Arecont, Axis, Bosh, Brickom, Canon, Sunell (Onvif), Panasonic, Pelco, Psia, Samsung, Sanyo, Sony, Vivotek, Zavio
Port Ethernet	10/100/1000 Base-TX (RJ-45)
Video compression	H.264
Recording modes	Continuous, schedule, manual, alarm triggered
Digital zoom	Any part of the image to full screen size
Protocols	TCP, UDP, RTP, DHCP, DDNS, SMTP, NTP, PPPoE, SADP, SNMP, NFS, iSCSI, UPnP, IPv6, ONVIF, PSIA, RTSP
Backup	External storage device via USB; PC or network drive via LAN
Client app	iVMS - 4200
Video outputs	HDMI, VGA (D-Sub)
Other interfaces	2 x USB, RS485
Remote client OS	Windows, Mac OS
Operating temperature	-10°C ... 55°C
Supplying voltage	230 VAC
Power consumption	10 W (without an HDD)
Mobile access	Android, iPad, iPhone
Compatible browsers	IE, Google Chrome, Opera, Safari
Dimensions (WxDxH)	315 x 230 x 45 mm
Weight	2 kg

Detalji

Detalji
Akcija	Ne
Akcija	Ne
Težina kg	10.000000

Osnovni pojmovi

Kratkog opis osnovnih pojmova videonadzor kamera
IR	IR svijetlo. Ovisno od kamere do kamere može biti od 20 do 120 metara ili više metara (EXIR tehnologija)
LED	LED svijetlo je vidljivo svijetlo koje koriste kamere s nocnim radom u boji. Ovisno od kamere do kamere može biti od 20 ili više metara
IP66, IP67	zaštita od vlage i vode. Oznaka da je kamera 100% otporna
IK10	zaštita od udaraca – antivandal kamera
HCL	je značajka koja je nastala zbog prekomjerne ekspozicije od jakih izvora svjetlosti poput svjetala ili reflektora. HLC je vrlo korisno u sprečavanju zasljepljivanja sigurnosnih kamera noću. Čitljivost registarske pločice na parkiralištu na ulaznim točkama.
Frame rate fp/s	broj snimljenih slika u sekundi
Auto Iris	Mehanička funkcija objektiva, koja automatski regulira protok svjetla na senzor kamere.
AWB	Auto Whitte balans je elektronski proces u video kamerama a koristi se da se dobiju realne boje na temelju bijele boje. Proces se odvija na bazi bijelog objekta u slici.
IP kamere	To su Internet protokol kamere namjenjene za rad putem LAN mreze ili UTP kabla.
TURBO HD ili HDTVI, HDCVI, AHD	Nudi video snimak visoke kvalitete putem koaksialnog kabela, idealan za stara ozičenja.
BLC	kompenzacija pozadinskog osvjetljenja
PoE	Power Over Ethernet – napajanje kamera putem UTP kabela, napajanje direktno iz PoE snimaca ili PoE switch-a.
Auto Iris	Mehanička funkcija objektiva, koja automatski regulira protok svjetla na senzor kamere.
CCTV	Close Circuit TV ( Slobodan prijevod Interna TV ) U Hrvatskoj koristimo naziv Video nadzor.
H.264	H.264 je standard za video kompresiju te je ekvivalent za MPEG-4 Part 10, ili MPEG-4 AVC (za Advanced Video Coding ).
Lux	Jedinica mjere za nivo svjetla definirana kada svjetlosni tok od 1 lumena padne na područje od 1 m2.
Min. Illumination	Minimalno osvjetljenje (osjetljivost kamere ) potrebno za rad kamere Osjetljivost kamere povezana je sa F-STOP objektiva , refleksije sa objekta i topline boje. Što je veći F-STOP to je potrebno više svjetla i obratno. Napr: za istu kameru ako je 1Lux / F2,0 onda je 0,5 Lux / F1,4.
Progressive scan	Progresivno skeniranje - način izrade slike tako da se skeniraju sve linije po redu. Bolja slika.
Real Time	Prikaz slike u stvarnom vremenu daje se obično kod DVR-ova, Multiplexera itd.
Resolution	Broj Horizontalnih TV linija za analogne uređaje ili broj točaka (pixela ) za digitalne uređaje.
Rezolucija snimanja	Određuje koliko maksimalno kvalitetno uređaj za snimanje može snimati neki video signal. Rezolucija prikazivanja slike odnosi se na cijeli ekran bez obzira na broj video ulaza ( kamera ). Rezolucija snimljenog materijala ovisi u kojoj je rezoluciji snimam svaki kanal.
Objektiv	Optička komponenta koja se sastoji od jednog ili više elementa optičkog stakla - specijalno brušenih leća.
PinHole Lens	Optika fiksnog irisa koja koristi vrlo malen otvor za diskretan nadzor prostora
