Featuring powerful optical zoom and accurate pan/tilt/zoom performance, the IP kamera Dahua STARLIGHT provides a large monitoring range and great detail. Equipped with the latest starlight technology, it offers excellent low light performance, capturing color details in challenging low-light applications down to 0.005 lux.
The camera utilizes wide dynamic range (WDR) technology to achieve vivid images even in intense contrast lighting conditions. True WDR (120 dB) optimizes both bright and dark areas of a scene simultaneously, ensuring usable video in applications with rapidly changing lighting conditions.
With auto-tracking functionality, the camera can automatically track and keep an object in motion within the scene. This feature can be triggered manually or automatically by defined rules. Once a rule is triggered, the camera zooms in and tracks the defined target automatically.
The IP kamera Dahua STARLIGHT utilizes Smart H.265+ technology, which reduces bit rate and storage requirements by up to 70% compared to standard H.265 video compression. This optimized implementation of the H.265 codec delivers high-quality video without straining the network.
PFA (Precise Focus Adjustment) technology ensures clarity throughout the zooming process and shortens focus time. It introduces new methods of judgment to ensure accurate and predictable subject distance adjustment, improving user experience and increasing product value.
Designed for extreme temperature environments, the Dahua camera operates in temperatures from -40 °C to +70 °C (-40 °F to +158 °F) with 95% humidity. It is subjected to rigorous dust and water immersion tests and certified with an IP66 Ingress Protection rating, making it suitable for demanding outdoor applications.
With TVS 6KV lightning protection rating, the camera provides lightning protection, surge protection, and voltage transient protection. It is built to withstand harsh conditions in outdoor settings.
The IP kamera Dahua STARLIGHT is interoperable and conforms to the ONVIF (Open Network Video Interface Forum) specifications, ensuring compatibility between network video products from different manufacturers.
1/2.8” 2Megapixel STARVIS™ CMOS; ICR, H.265,
Triple-streams encoding, BLC/HLC/AWB/AGC/3DNR/WDR(120db),
2MP(1~50fps), 4.8-120.0mm, auto focus, 16x digitalni zoom,
Max 400°/s pan speed, 360° endless pan rotation,
2/1 Alarm in/out, 1/1 audio in/out, Micro SD,
Max 128GB, IC 100m, IP66, AC24V/PoE+;
Podržava video analitiku i Auto tracking
System Overview Featuring powerful optical zoom and accurate pan/tilt/zoom performance, this camera can provide large monitoring range and great detail. The camera has very excellent low light performance due to adopting the latest starlight technology . The camera is equipped with smooth control, high quality image and good protection, which make it can meet most of the requirements of video surveillance applications. Functions Starlight Technology For challenging low-light applications, Dahua’s Starlight Ultra-low Light Technology offers best-in-class light sensitivity, capturing color details in low light down to 0.005 lux. The camera uses a set of optical features to balance light throughout the scene, resulting in clear images in dark environments. Wide Dynamic Range The camera achieves vivid images, even in the most intense contrast lighting conditions, using industry-leading wide dynamic range (WDR) technology. For applications with both bright and low lighting conditions that change quickly, True WDR (120 dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video. Auto-tracking This feature controls the pan/tilt/zoom actions of the camera to automatically track an object in motion and to keep it in the scene. The tracking action can be triggered manually or automatically by defined rules. Once a rule is triggered, the camera can zoom in and track the defined target automatically. Smart H.265+ Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces bit rate and storage requirements by up to 70% when compared to standard H.265 video compression. PFA Technology PFA technology has innovatively introduced new methods of judgment to ensure the accuracy and predictability of the direction of subject distance adjustment. The result is a set of advanced focusing algorithms. PFA ensures clarity of the image throughout the process of zooming and shortens focus time. The realization of PFA technology substantially improves user experience and increases product value. Environmental Dahua cameras operate in extreme temperature environments, rated for use in temperatures from -40 °C to +70 °C (-40 °F to +158 °F) with 95% humidity. Subjected to rigorous dust and water immersion tests and certified to the IP66 Ingress Protection rating makes it suitable for demanding outdoor applications. Protection This camera suits even the harsh conditions for outdoor applications. TVS 6KV lightning protection rating provides lightning protection, surge protection and voltage transient protection. Interoperability The camera conforms to the ONVIF (Open Network Video Interface Forum) specifications, ensuring interoperability between network video products regardless of manufacturer.
Is Featured | Ne |
---|---|
Weight kg | 5000.000000 |
Kratkog opis osnovnih pojmova videonadzor kamera | |||||
---|---|---|---|---|---|
IR | IR svijetlo. Ovisno od kamere do kamere može biti od 20 do 120 metara ili više metara (EXIR tehnologija) | ||||
LED | LED svijetlo je vidljivo svijetlo koje koriste kamere s nocnim radom u boji. Ovisno od kamere do kamere može biti od 20 ili više metara | ||||
IP66, IP67 | zaštita od vlage i vode. Oznaka da je kamera 100% otporna | ||||
IK10 | zaštita od udaraca – antivandal kamera | ||||
HCL | je značajka koja je nastala zbog prekomjerne ekspozicije od jakih izvora svjetlosti poput svjetala ili reflektora. HLC je vrlo korisno u sprečavanju zasljepljivanja sigurnosnih kamera noću. Čitljivost registarske pločice na parkiralištu na ulaznim točkama. | ||||
Frame rate fp/s | broj snimljenih slika u sekundi | ||||
Auto Iris | Mehanička funkcija objektiva, koja automatski regulira protok svjetla na senzor kamere. | ||||
AWB | Auto Whitte balans je elektronski proces u video kamerama a koristi se da se dobiju realne boje na temelju bijele boje. Proces se odvija na bazi bijelog objekta u slici. | ||||
IP kamere | To su Internet protokol kamere namjenjene za rad putem LAN mreze ili UTP kabla. | ||||
TURBO HD ili HDTVI, HDCVI, AHD | Nudi video snimak visoke kvalitete putem koaksialnog kabela, idealan za stara ozičenja. | ||||
BLC | kompenzacija pozadinskog osvjetljenja | ||||
PoE | Power Over Ethernet – napajanje kamera putem UTP kabela, napajanje direktno iz PoE snimaca ili PoE switch-a. | ||||
Auto Iris | Mehanička funkcija objektiva, koja automatski regulira protok svjetla na senzor kamere. | ||||
CCTV | Close Circuit TV ( Slobodan prijevod Interna TV ) U Hrvatskoj koristimo naziv Video nadzor. | ||||
H.264 | H.264 je standard za video kompresiju te je ekvivalent za MPEG-4 Part 10, ili MPEG-4 AVC (za Advanced Video Coding ). | ||||
Lux | Jedinica mjere za nivo svjetla definirana kada svjetlosni tok od 1 lumena padne na područje od 1 m2. | ||||
Min. Illumination | Minimalno osvjetljenje (osjetljivost kamere ) potrebno za rad kamere Osjetljivost kamere povezana je sa F-STOP objektiva , refleksije sa objekta i topline boje. Što je veći F-STOP to je potrebno više svjetla i obratno. Napr: za istu kameru ako je 1Lux / F2,0 onda je 0,5 Lux / F1,4. | ||||
Progressive scan | Progresivno skeniranje - način izrade slike tako da se skeniraju sve linije po redu. Bolja slika. | ||||
Real Time | Prikaz slike u stvarnom vremenu daje se obično kod DVR-ova, Multiplexera itd. | ||||
Resolution | Broj Horizontalnih TV linija za analogne uređaje ili broj točaka (pixela ) za digitalne uređaje. | ||||
Rezolucija snimanja | Određuje koliko maksimalno kvalitetno uređaj za snimanje može snimati neki video signal. Rezolucija prikazivanja slike odnosi se na cijeli ekran bez obzira na broj video ulaza ( kamera ). Rezolucija snimljenog materijala ovisi u kojoj je rezoluciji snimam svaki kanal. | ||||
Objektiv | Optička komponenta koja se sastoji od jednog ili više elementa optičkog stakla - specijalno brušenih leća. | ||||
PinHole Lens | Optika fiksnog irisa koja koristi vrlo malen otvor za diskretan nadzor prostora |
