This Hybrid Mrežna PTZ camera from Dahua is equipped with advanced features to provide exceptional video surveillance for outdoor applications. With its dual lens system and Pan/Tilt/Zoom (PTZ) capabilities, it offers a comprehensive solution for capturing long-distance footage.
The Hybrid Mrežna PTZ camera combines a thermal camera and a visible camera, making it ideal for dark, long-range monitoring applications. The thermal camera provides monitoring capabilities in total darkness, while the visible camera with starlight feature and motorized lens confirms details.
This camera supports auto-tracking, which can be triggered manually or automatically based on defined rules. Once triggered, the camera will zoom in and track the defined target automatically.
Designed for extreme temperature environments, this camera can operate in a temperature range of -40°C to +70°C (-40°F to +158°F). It is subjected and certified to rigorous dust and water immersion tests, boasting an IP66 rating for demanding outdoor applications. Additionally, it is equipped with an integrated wiper for clear visibility in rainy, snowy, or foggy conditions.
This camera is built to withstand unstable conditions with its ±25% input voltage tolerance. It also has a 6KV lightning rating, providing protection against the effects of lightning for both the camera and its structure.
· 640*512 VOx uncooled thermal sensor technology
· Athermalized Lens(thermal),Focus-free
· 1/1.9” 2Megapixel progressive scan Exmor CMOS
· Powerful 30x optical zoom
· Support Fire detect&alarm
· Max 160°/s pan speed, 360° endless pan rotation
· Up to 300 presets, 5 auto scan, 8 tour, 5 pattern
· 7/2 alarm in/out
· Micro SD memory, IP66
Auto-tracking
AC24V IP66
System Overview
Featuring a dual lens, Pan/Tilt/Zoom(PTZ) camera, this series provides an all-in-one solution for capturing long distance video surveillance for outdoor applications. Together with Thermal and Starlight Technology, the camera is the perfect solution for dark, long rang monitoring applications. The series combines one thermal camera for monitoring in total darkness and one visible camera with starlight feature and motorized lens for confirming details.
Functions
Uncooled Vox Technology
Dahua thermal cameras use uncooled Vox sensor technology . Because of small size and better performance, it’s cost-effective solution for thermal security.
High Sensitivity
High thermal sensitivity(<40mK) makes cameras capture more image details and temperature difference information.
Fire Detect&Alarm
With built-in Fire detect function, the camera has the ability to detect fire in a long distance. because thermal camera is sensitive to temperature, so the accuracy of Fire detect will be higher than visible camera. especially useful for forest fire prevention.
Intelligent Video System (IVS)
With built-in intelligent video analytics, the camera has the ability to detect and analyze moving objects for improved video surveillance. The camera provides optional standard intelligence at the edge allowing detection of multiple object behaviors such as abandoned or missing objects. IVS also supports Tripwire analytics, allowing the camera to detect when a pre-determined line has been crossed.
The camera supports auto-tracking. The tracking action can be triggered manually or automatically by defined rules. Once rules are
triggered, the camera can zoom in and track the defined target automatically.
Environmental
With a temperature range of-40 °C to +70 °C (-40 °F to +158 °F), the camera is designed for extreme temperature environments. Subjected and certified to rigorous dust and water immersion tests, the IP66 rating makes it suitable for demanding outdoor applications. For enviorments with rain, sleet, snow and fog, an integrated wiper provides users with clear visibility at all times.
Protection
Supporting ±25% input voltage tolerance, this camera suits even the most unstable conditions for outdoor applications. Its 6KV lightning rating provides protectection against the camera and its structure from the effects of lightning.
| Is Featured | Ne |
|---|---|
| Is Featured | Ne |
| Weight kg | 18000.000000 |
| Kratkog opis osnovnih pojmova videonadzor kamera | |||||
|---|---|---|---|---|---|
| IR | IR svijetlo. Ovisno od kamere do kamere može biti od 20 do 120 metara ili više metara (EXIR tehnologija) | ||||
| LED | LED svijetlo je vidljivo svijetlo koje koriste kamere s nocnim radom u boji. Ovisno od kamere do kamere može biti od 20 ili više metara | ||||
| IP66, IP67 | zaštita od vlage i vode. Oznaka da je kamera 100% otporna | ||||
| IK10 | zaštita od udaraca – antivandal kamera | ||||
| HCL | je značajka koja je nastala zbog prekomjerne ekspozicije od jakih izvora svjetlosti poput svjetala ili reflektora. HLC je vrlo korisno u sprečavanju zasljepljivanja sigurnosnih kamera noću. Čitljivost registarske pločice na parkiralištu na ulaznim točkama. | ||||
| Frame rate fp/s | broj snimljenih slika u sekundi | ||||
| Auto Iris | Mehanička funkcija objektiva, koja automatski regulira protok svjetla na senzor kamere. | ||||
| AWB | Auto Whitte balans je elektronski proces u video kamerama a koristi se da se dobiju realne boje na temelju bijele boje. Proces se odvija na bazi bijelog objekta u slici. | ||||
| IP kamere | To su Internet protokol kamere namjenjene za rad putem LAN mreze ili UTP kabla. | ||||
| TURBO HD ili HDTVI, HDCVI, AHD | Nudi video snimak visoke kvalitete putem koaksialnog kabela, idealan za stara ozičenja. | ||||
| BLC | kompenzacija pozadinskog osvjetljenja | ||||
| PoE | Power Over Ethernet – napajanje kamera putem UTP kabela, napajanje direktno iz PoE snimaca ili PoE switch-a. | ||||
| Auto Iris | Mehanička funkcija objektiva, koja automatski regulira protok svjetla na senzor kamere. | ||||
| CCTV | Close Circuit TV ( Slobodan prijevod Interna TV ) U Hrvatskoj koristimo naziv Video nadzor. | ||||
| H.264 | H.264 je standard za video kompresiju te je ekvivalent za MPEG-4 Part 10, ili MPEG-4 AVC (za Advanced Video Coding ). | ||||
| Lux | Jedinica mjere za nivo svjetla definirana kada svjetlosni tok od 1 lumena padne na područje od 1 m2. | ||||
| Min. Illumination | Minimalno osvjetljenje (osjetljivost kamere ) potrebno za rad kamere Osjetljivost kamere povezana je sa F-STOP objektiva , refleksije sa objekta i topline boje. Što je veći F-STOP to je potrebno više svjetla i obratno. Napr: za istu kameru ako je 1Lux / F2,0 onda je 0,5 Lux / F1,4. | ||||
| Progressive scan | Progresivno skeniranje - način izrade slike tako da se skeniraju sve linije po redu. Bolja slika. | ||||
| Real Time | Prikaz slike u stvarnom vremenu daje se obično kod DVR-ova, Multiplexera itd. | ||||
| Resolution | Broj Horizontalnih TV linija za analogne uređaje ili broj točaka (pixela ) za digitalne uređaje. | ||||
| Rezolucija snimanja | Određuje koliko maksimalno kvalitetno uređaj za snimanje može snimati neki video signal. Rezolucija prikazivanja slike odnosi se na cijeli ekran bez obzira na broj video ulaza ( kamera ). Rezolucija snimljenog materijala ovisi u kojoj je rezoluciji snimam svaki kanal. | ||||
| Objektiv | Optička komponenta koja se sastoji od jednog ili više elementa optičkog stakla - specijalno brušenih leća. | ||||
| PinHole Lens | Optika fiksnog irisa koja koristi vrlo malen otvor za diskretan nadzor prostora | ||||
